• Automatic pallet shrink wrapping machine is designed to wrap varied bottles with different filling materials, such as beer, beverage, food, and with different bottle materials, like glass and plastic.
• Designed with different models.
• Single linear shrink wrapper can pack 10-45 cartons per minute.
The principle of operation
• Concise structure, attractive appearance, unique design, convenient to maintain.
• Big screen LCD display offers both English and Chinese operating interface.
• Air expanding shaft is fitted into the core of the shrink wrap roll for quick, easy roll change in a couple of minutes.
• Web tension is precisely controlled to ensure flat, even shrink wrap surface. A high level of cutting accuracy makes sure each shrink film is cut in a tidy manner.
• Super servo controlling technology can keep each fracture precision in-phase, and keep transmission work stability.
• Heating case fracture is reasonable, heat insulation and warm keeping, temperature controlling precision is highly.
• Matched with German Siemens, German p+f, Japan SMC, Italy Motuoliao, and other world famous controlling component, so the working condition is steady.
• Mechanical drive part is made pf heat treated stainless steel, medium carbon steel and etc., so fine surface coating is applied, which leads to an excellent rust resistance.
• All electrical and pneumatic elements of the automatic shrink wrap machine are built to the latest CE requirements
• When there is a power outage, manpower rotary conveyor belt device could be activated for easier moving for product from inside.
|Power||AC380V 50/60HZ 37.5KW|
|Wrapping Speed||10-12 bags/Min|
|Packs||length:200-530mm width:110-350mm height:70-360mm|
|Pad size||3mm thickness|
|Film||material :LDPE thickness:30-100um Max. Film roll diameter:500mm; film reel core diameter:76mm|
